Safety Cabinets with Fire Detection

Fire-Resistant Safety Cabinets with Integrated Fire Detection for Lithium Battery Storage.

Maximum Battery Capacity: ≤ 3,500 Wh
Maximum Total Energy Capacity: ≤ 14,000 Wh
External Dimensions (H × W × D): 2120 × 1502 × 903 mm
Internal Dimensions (H × W × D): 1685 × 1350 × 695 mm
Weight: 702 kg
Safety Features: Self-closing doors with a key lock, 100 mm diameter ventilation openings, and an earthing (grounding) point. Door hold-open system with automatic thermally activated self-closing at 47°C.
Pictograms: Standardized in accordance with the French Technical Recommendation RT 362.
Ventilation: Ventilation outlets designed for connection to a CDV-A ventilation unit.
